THIS IS A "WORK IN PROGRESS" POST. I am currently working on this project and taking notes here. Feel free to read along, but please excuse any incomplete thoughts or random links as I am using it as a personal reference. Stay tuned for more!

I'm going as Lady Gaga from this year's VMA's for halloween. It's a perfect costume because I'll need to be wearing a mask anyway!

I started by collecting all the images that I could find on the Pinterest board above so that I can gather as many angles as possible.

Displays to consider

First, I'm looking into the display of LEDs. Looking close up, you can see that it is an LED matrix with 9 sections of LEDs arranged 8 x 8. It looks like they may have used something similar (or exactly) this matrix from Adafruit:

The only trouble with this is that each matrix is $25 and I would need 9 of them- so $225 just for the LEDs! That is a bit too much.

Then, I learned about this circular display from a recommendation on the Adafruit Discord. It's the right size and I could potentially fake the look of the LED Matrix with a processing sketch and a raspberry pi zero.

The display looks like it could be a real winner, but I don't think of Raspberry Pi when I think wearables - especially something on my face. How will I power it?

I could also go for an LED matrix with less pixel density and not break the bank by using this 8 x 8 NeoPixel matrix.Sine Wave by Daniel Shiffman.It isn't the same amount of pixels from Gaga's mask, but it's significantly cheaper and certainly reminiscent enough of the real thing to pass as a costume piece. It's pictured with the inside circle from a 3-inch embroidery hoop.

Sine Wave Code

I started in Processing because that was the language I learned to code graphics in, and I wanted to understand it visually before I dug into the text of the code.

I found this fantastic and simple example of exactly what I was looking for: CLICK HERE

Here's a video that explains the code:

Next, I translated it to work with the Arduino IDE and the DotStar Matrix.

Here's the Arduino code so far. This generates a pink sine wave on the 24 x 24 matrix. Next, I'll add the microphone so that I can change the amplitude of the wave when I talk.

/*
  This code creates a sin wave on a 24 x 24 DotStar LED Matrix consisting of 9, 8 x 8 Matrices


*/


#include
#include
#include


#define DATAPIN  12
#define CLOCKPIN 13


#define ONBOARDDATAPIN 8
#define ONBOARDCLOCKPIN 6


#define BRIGHTNESS 16


// Define matrix width and height.
#define mw 24
#define mh 24


#define TWO_PI 6.283185307179586476925286766559


Adafruit_DotStar onboardDotStar(1, ONBOARDDATAPIN, ONBOARDCLOCKPIN, DOTSTAR_BRG);
Adafruit_DotStarMatrix matrix = Adafruit_DotStarMatrix(
                                  (uint8_t)8, (uint8_t)8, 3, 3, DATAPIN, CLOCKPIN,
                                  DS_TILE_TOP   + DS_TILE_LEFT   + DS_TILE_ROWS   + DS_TILE_PROGRESSIVE +
                                  DS_MATRIX_TOP + DS_MATRIX_LEFT + DS_MATRIX_COLUMNS + DS_MATRIX_PROGRESSIVE,
                                  DOTSTAR_BGR);


uint32_t magenta = matrix.Color(255, 0, 255);


//WAVELENGTH ATTRIBUTES


int widthOfWholeWave = 24; // Width of the entire wave, I'm using a 24 x 24 matrix.
int wavelength = 12; // How much distance between wave peaks
float velocity = 0.0; // How much does the wave increment / How fast it moves
int amplitude = 8; // How tall is the wave? (Above and below the center)
int xIncrement; // Needed to increment the x values
int yValues[24]; // Stores height values for the wave, I'm using a 24 x 24 matrix.


void setup() {


  // Serial
  Serial.begin(9600);


  // DotStar Setup Stuff
  onboardDotStar.begin(); // initialize the onboard DotStar LED
  onboardDotStar.show(); // Turns off the onboard DotStar LED (It has nothing to show for itself!)
  matrix.begin(); // initialize the matrix
  matrix.setBrightness(BRIGHTNESS); // set the brightness
  matrix.clear(); // clear the matrix just in case


  // Sine Wave Setup Stuff
  xIncrement = (TWO_PI / wavelength) * widthOfWholeWave;
}


void loop() {


  matrix.clear();
  calculateWave();
  drawWave();
  matrix.show();
}


void calculateWave() {


  velocity = velocity + 100;
  float x = velocity;

  for (int i = 0; i < mh; i++) {
    yValues[i] = sin(x) * amplitude;
    x += xIncrement;
  }
}


void drawWave() {


  for (int i = 0; i < mh; i++) {
    matrix.drawPixel(i, mh / 2 + yValues[i], magenta);
  }


}
